CM-2510 & CM-2520 Series Double Gang Push Plate Switches

CM-2510 Series combination key switch and push plate switch is an attractive means for enabling/disabling an automatic operator. CM-2520 Series vestibule switches offer a convenient and economical control of two doors.

CM-2510 and CM-2520 push plate switches have 4-1/2" x 4-1/2" rectangular faceplates designed for easy installation directly on a double gang electric box. The tubular switches provide virtually silent operation.

CM-2510 includes a SPST maintained switch. Mortise cylinder and keys are sold separately.

Architectural Finishes:
CM-2510 Series switches with architectural finish
only available with /2, /4, /8 graphic options

CM-2520 Series switches with architectural finish
only available with /48 graphic option

Features

•	Heavy Duty Stainless steel construction
•	ADA compliant
•	Minimal actuation force
•	3 year warranty with '2 for 1' replacement

Specifications

Std. Finish:	US32 / C32D
Contact Type:	N/O SPST Momentary
Contact Type:	N/O SPST Maintained
Contact Rating:	3 A @ 30 VDC
Contact Rating:	6 A @ 30 VDC
Temp Range:	-40°F to 140°F (-40°C to +60°C)
Dimensions:	4-1/2" x 4-1/2" x 1-3/16" (114mm x 114mm x 30mm)
Dimensions:	4-1/2" x 4-1/2" x 1-3/4" (114mm x 114mm x 44mm)

Models

Mortise Cylinders (Sold Separately)
CM-2510		Double Gang Push Plate/Key Switch . . . more Double Gang Push Plate/Key Switch . . . Not compatible with 4-1/2" Square AURA(tm) illuminated switch enclosurers . . . less
CM-2520		Double Gang Vestibule Push Plate Switch
CM-CYL60-KA		Mortise cylinder 1 1/8 inch, solid brass, chrome finish, keyed alike
CM-CYL60-KD		Mortise cylinder as above, keyed different
