CX-247 7 Day Timer

With 16 flexible daily or weekly (on/off) schedules the CX-247 can automatically activate/deactivate electric locks and magnets, automatic doors; or control lighting or energy management devices. Very compact, and easy to program and install.

Camden's CX-247 is an affordable, compact and easy to program 7 day electronic timer that is designed for use in a wide range of control applications. The unit supports up to 16 'on/off' scheduled times per day and is available in 12 or 24 Volt models.

Applications: Ideal for automatic enable/disable of door activation devices, lighting control, energy management and other general control applications.

Features

•	15 daily or weekly schedules
•	Internal memory back-up
•	Easy to program/setup
•	Extremely compact size
•	12 and 24V AC/DC models
•	SPDT contacts rated 16 amps @ 30 VDC
•	Dimensions: 2-3/8" x 2-3/8" x 1-1/4"
•	3 year warranty

Specifications

Voltage:	12V AC/DC or 24V AC/DC
Current Draw:	0.1 mA Idle, 10 mA Operating
Response Time:	0.3 Seconds
Backup:	Internal Permacell
Programs:	16
Output:	Form 'C' (SPDT)
Contact Rating:	16 A @ 30 VDC
Electrical Life:	250,000 @ Rated Capacity
Dimensions:	2-3/8" x 2-3/8" x 1-1/4" (60mm x 60mm x 32mm)

Models

CX-247-12		7 day timer - 12 V
CX-247-24		7 day timer - 24 V
CX-247H-12		7 day timer with first-man-in function - 12 V
CX-247H-24		7 day timer with first-man-in function - 24 V
